◆ Voltage : 110V~240V/50-60Hz
◆ Ballast : Electronic ballast
◆ Lamp : YODN230W R7 ,Color temperature : 8500K
◆ Average Lifespan : 2000H
◆ Color : 14 color + blank color wheel
◆ Gobo : 17 fixed gobo + blank gobo
◆ Prism : rotation 8-face prism, Bilateral rotation .
◆ Lens : high precision optical lens
◆ Wash effect : adjustable Wash effects angle
◆ Focus : linear adjustment
◆ Dimmer : 0-100% linear adjustment
◆ Pan/Tilt : X axis 540° Y axis 250°automatically accurate positioning
◆ Beam angle : parallel beam angel 0 – 3.8°
◆ Strobe : Double lens strobe (0.5-9 times/ second)
◆ Control mode : Standard DMX512, Automatic and Master/ slave mode
◆ Channel : 16 CH
◆ Controller can open the lamp and reset, including delaying function
◆ Weight : 18.5KG
Channel Control Description
1CH | X axis |
2CH | Y axis |
3CH | X-axis fine-tuning |
4CH | Y-axis fine-tuning |
5CH | X, Y speed |
6CH | atomization |
7CH | strobe |
8CH | open light |
9CH | color plate |
10CH | color wheel speed |
11CH | pattern |
12CH | pattern jitter |
13CH | Focusing |
14CH | Prism |
15CH | Prism rotation |
16CH | 100-105 foam 200-205 bright bubble 255 reset |
