IP65 Waterproof LED 10*60W Moving Bar with Fill Light

IP65 Waterproof LED 10*60W Moving Bar with Fill Light

Specification:

Optical System

Input Power: AC90-240V~50/60Hz

Power: 800W

Light Source: 10*60W RGBW LED

96*3W CW LED

96*3W WW LED

96*0.5W RGB LED

Beam Angle: 2.8°-31°

Spot Angle: 5°-46°

Total Light Output: 60000 1m (instantaneous flicker)

Illuminance: 24000 Lux (3°) at 3 meters

Color Temperature: 2700K～8000K

Color Rendering Index: WW:≥90

Light Source Lifespan: 20000 hours

Color System

Color: RGBW+CW+WW mixed color

Effect Configuration

Dim/Flicker: 0%-100% smooth dimming, multiple flicker speeds

Y-axis Movement Angle: 202°

Control and Programming

DMX512 Channel Modes: 17/27/99/108/168/170CH

Control Protocol: DMX512, RDM, (Art-Net, sACN optional)

Structure: OLED Display

Connection: 3-core DMX signal cable input/output, maximum connection quantity 32 units

Protection Rating IP65 Operating Environment: -10℃~45℃

Cooling System: Low-noise fan forced ventilation

Dimensions and Weight

Dimensions: 1010*126*370mm 31.3kg

Packaging Dimensions: 1700*430*250mm 33.55kg

Features: Linear scaling system, full and sharp beam, excellent color rendering effect
