Input voltage: AC90-240V 50HZ/60HZ
Whole power: 1400W
Light source specifications: 784pcs RGB0.5W ultra-bright light source, 392pcs white light 3W ultra-bright light source
Approved life: 50,000 hours
Color: Red, green, blue, white, multiple colors, infinitely changeable
Light source control: RGB 14-segment zone control, white light 28-segment zone control
Vertical direction: 220° (16 bit precision scanning)
The Y axis is driven by a high-speed silent 60 three-phase thickened motor, which makes the operation faster and smoother.
It can automatically return to its original position after a misoperation, and the vertical speed is adjustable;
the Y axis has the function of rotation and reversal; it uses photoelectromagnetic encoding for high-precision positioning
Electronic strobe: 0.3-25 times/second
Dimming: Electronic dimming 0-100% linear adjustment, with gamma curve dimming frequency 1.2K-25K adjustable, with macro instruction dimming linear, stable,
smooth and flicker-free, using stable constant current drive and power supply, suitable for video shooting
Control mode: 24CH (simplified) 8CH/11CH/13CH/24CH/30CH/74C H/97CH (standard) 7 channel control modes, standard DMX512 protocol, RDM protocol
Power connection method: power input and output, maximum connection quantity @2 units 230V, 1 unit 120V
Signal connection method: DMX512 input and output, 3-core maximum connection quantity 30 units
Support network protocol Artnet
Display function: LCD touch screen, Chinese and English bilingual menu, sensor fault display, temperature display
Cooling system: High-conductivity light aluminum radiator, fan intelligent monitoring technology automatically adjusts the fan speed according to the temperature of the lamp,
built-in overheating protection intelligent system/intelligent temperature and noise balance module
Protection level: IP65
Gross weight: 17KG
Net weight: 15KG
Product size: 404*202*350MM
