Voltage  | 110V~240V/50-60Hz  |
Ballast  | Electronic ballast  |
Lamp  | YODN230W R7 ,Color temperature 8500K  |
Average Lifespan  | 2000H  |
Color  | 14 color + blank color wheel  |
Gobo  | 17 fixed gobo + blank gobo  |
Prism  | rotation 8-face prism, Bilateral rotation .  |
Lens  | high precision optical lens  |
Wash effect  | adjustable Wash effects angle  |
Focus  | linear adjustment  |
Dimmer  | 0-100% linear adjustment  |
Pan/Tilt  | X axis 540° Y axis 250°automatically accurate positioning  |
Beam angle  | parallel beam angel 0 – 3.8°  |
Strobe  | Double lens strobe (0.5-9 times/ second)  |
Control mode  | Standard DMX512, Automatic and Master/ slave mode  |
Channel  | 16 CH Controller can open the lamp and reset,including delaying function  |
Weight  | 18.5KG  |
Channel Control Description
1CH  | X axis  |
2CH  | Y axis  |
3CH  | X-axis fine-tuning  |
4CH  | Y-axis fine-tuning  |
| 5CH | X, Y speed  |
| 6CH | atomization  |
7CH  | strobe  |
8CH  | open light  |
9CH  | color plate  |
10CH  | color wheel speed  |
11CH  | pattern  |
12CH  | pattern jitter  |
| 13CH | Focusing  |
| 14CH | Prism  |
| 15CH | Prism rotation  |
| 16CH | 100-105 foam 200-205 bright bubble 255 reset  |
