LED 600W Beam Spot Wash with CMY CTO

Download User's Manual:

LED600W BSW MANUAL.pdf

Video:

Specification:

Input voltage: 100~240V AC, 50/60Hz

Rated power: 800W@220V

Light source: 550W LED

Rated life: 20,000 hours

Illumination: 168,000LUX at a distance of 5 meters

Beam angle: 3°~40°

Color temperature: 7000K

Rotation angle: 540° horizontal and 270° vertical; with automatic return function

Strobe: 0~30HZ

Color: 1 color disk, (8 colors + white light), CMY, CTO

Gobo: 1 fixed gobo disk (12 gobos + white light), 7 rotating gobo effects

Prism: 8 prisms + single six-row prism

Dimming: 0-100% linear adjustment

Atomization: independent atomization

Focus: DMX linear adjustment

Control mode: DMX512, RDM, master-slave synchronous control mode, self-propelled mode, single scene mode

Channel: 22CH/26CH

Protection level: IP20

Casing: High-temperature resistant flame retardant plastic

Power connection: powerCON power input/output

Signal connection: three-core DMX signal input/output
