 ◆ Control channel :  2 DMX channel mode, standard mode 12 channels, extended 14 channel mode
 ◆ LED light source :  100W high brightness COB light source
 ◆ dimming :  0% ~ 100% linear dimming / S curve / square / open square four dimming mode
 ◆ Strobe :  independent electronic strobe
 ◆ control mode :  international standard DMX512 signal, master and slave, voice control
 ◆ fan control :  intelligent speed control
 ◆ LED over-temperature protection :  the use of advanced electronic temperature detection device, intelligent control LED
Color rendering index
  ◆ (CRI) :  95
 ◆ Spot angle :  53º
 ◆ Beam angle :  68º
 ◆ Input voltage :  100-240V / 50-60Hz
 ◆ Power :  430W
 ◆ Ambient temperature :  -20 ℃ -40 ℃.
 ◆ Protection class :  IP20

CHAUVET PROFESSIONAL COLORdash Par H7IP RGBWAUV LED Wash Light
Light Source 7 LEDs (hex-color RGBAW+UV) 10 W, 500 mA
50,000 hours life expectancy
Color Temperature 2800 to 10,000K
Beam Angle 21°
Field Angle 47°
Illuminance 674 lux at 16.4' (5 m)
PWM Frequency Selectable: 600/1200/2000/4000/6000/25,000 Hz
Dimmer Electronic
Shutter/Strobe Electronic
Strobe Rate 0 to 30 Hz
Dimming Modes: 4
Power Connections Edison (Local plug to Seetronic Powerkon IP65)
Power Input Seetronic Powerkon IP65
Power Output Seetronic Powerkon IP65
Connectors Data: 5-pin IP65 XLR
Cable Length Power: 5' (1.5 m)
Control Protocol DMX, RDM
DMX Channels 6, 8, or 13
DMX Personalities 3 personalities (6, 8, 13)
Input Voltage 100 to 240 VAC, 50/60 Hz (auto-ranging)
Power Linking 26 units at 120 V
46 units at 208 V
50 units at 230 V
Power and Current 63 W, 0.52 A at 120 V, 60 Hz
63 W, 0.52 A at 120 V, 60 Hz
66 W, 0.28 A at 230 V, 50 Hz
Certifications CE, MET
IP Rating IP65
Ambient Temperature -4 to 113°F (-20 to 45°C)
Housing Material Aluminum die-cast
Gel Frame Holder 6.5" (165 mm)
Dimensions 11.02 x 9.44 x 6.06" (280 x 240 x 154 mm)
Weight 7.8 lb (3.6 kg)
